Home
/
Fishing Boats
/
Hudson
®
Series
/ Hudson
®
170 WS
Hudson
®
170 WS
2025
Enter your ZIP / Postal code
to see our prices and promotions
5.4 m
(17’-10”)
685 kg
(1510 lb.)
150 HP
(112 kW)
6
persons
Hudson
®
170 WS
2025
Go to section
Boat overview
Advantages
Gallery
Features and options
Configure
Request a quote
Picture 1
Picture 2
Picture 3
Picture 4
Previous
Next
Storage compartment
Livewell
Open space storage compartment
Rod storage compartment
Fuel tank
Ice box
Privacy enclosure
Our advantages
Optional 160-watt AM/FM/Bluetooth Jensen Stereo with integrated auxiliary input (1/8'') in console
2 folding seats
Storages integrated in the bow fishing platform
Drawer under driver console
Driver helm shown with in-dash Humminbird
®
Helix 7
Glove box in console
Large lockable rod organizer with tubes for 10 rods in the bow casting platform
Stern electric-filled aerated livewell (77 L/20 U.S. gal.)
Storage under passenger console
Trolling motor plug
View it in action
*
Walkaround video
*
360° Views
*
*
Not available for this specific model, a similar model is shown.
The displayed image or video may not represent the final product.
Previous
Next
Features and options
Features
Specifications
Options
HULL AND DECK FEATURES
5052-H36 marine grade aluminum alloy
NMMA & Transport Canada certified
Exterior urethane paint choices with a glossy finish including decal package
Reverse chine hull design
Aluminum clad transom
Deep self-draining splashwell
Twin plating from bow to mid-ship
Twin plating at the chine
Rigging tube under flooring (from helm to bow)
Rigging tube under flooring (from stern to helm)
Stainless steel bow and stern eyes
4 nylon cleats
BOW RAISED CASTING PLATFORM
Storage under casting platform
Compression latches on all storage
Deep cycle battery storage compartment
Seat mount floor base
Grids allowing air flow in the compartments
Large storage compartment
Large lockable rod organizer with tubes for 10 rods
AFT RAISED CASTING PLATFORM
Battery storage compartment
Electric-filled aerated livewell
Seat mount floor base
Splashwell extension
FISHING FEATURES
7-foot rod storage without support
12V or 24V bow trolling motor plug and wiring harness
Trolling motor plug with 60 AMP protection
Bow mounting trolling motor pad
Marine grade carpet front deck
BOW SPORTFLO ELECTRIC-FILLED AERATED LIVEWELL
STERN SPORTFLO ELECTRIC-FILLED AERATED LIVEWELL
Stern livewell (44", 77 L/20 U.S. gal.)
Overflow
Anti-spill cover
Protection filter on the filling pump
SEATS
6 floor seat bases
2 folding seats with no-pinch hinges
HELM
Twin consoles with steering system
Glove box
Drawer under driver helm
Black anodized walk-thru tempered glass windshield with door
Deluxe dash panel with switches and indicator lights
No-FeedBack dual cable steering system
Storage under consoles
12V outlet
INSTRUMENTATION
Tachometer, speedometer, voltmeter, trim, and fuel gauges
OTHER STANDARD FEATURES
All the flat surfaces are covered with anti-skid marine grade vinyl
PrinceTrak System: extrusion allowing onboard tool fixing
Electric bilge pump
2 bow handles
Navigation lights
Factory-installed snap fasteners for canvas enclosure and trailer cover options
Interior light(s)
5 handles
3 cup holders
3 battery holders
Emergency reboarding ladder
Transducer(s) mounting plate
Pressure-treated wood floor covered with marine grade vinyl
TRAILER STANDARD FEATURES
Standard galvanized bunk style trailer
Single axle with swing tongue
Carpeted fixed bunks and load guides
Built-in steps and composite fenders
Sealed hubs and swivel tongue jack
2" ball coupler
LED lighting
Factory balanced steel wheel
1 095 kg (2 415 lb) carrying capacity
Radial tire size : ST205/75R14 C
Weight: 202 kg (445 lb)
SPECIFICATIONS
Center line : 5.4 m (17’-10”)
Beam : 2.3 m (91”)
Chine width : 2.0 m (78")
Maximum depth : 0.9 m (35")
Approximate draft : 0.8 m (33")
Transom height : 0.6 m (25")
Approximate weight : 649 kg (1430 lb)
Dead rise (degres) : 13
TRANSPORT CANADA
Maximum HP Capacity : 150 HP (112 kW)
Maximum weight capacity : 685 kg (1510 lb)
Maximum weight person capacity : 375 kg (827 lb)
Maximum person capacity : 5
NMMA (USA)
Max. HP cap. : 150 HP (112 kW)
Max. weight cap. : 685 kg (1510 lb)
Maximum weight person capacity : 339 kg (748 lb)
Maximum person capacity : 6
ALUMINUM THICKNESS
Bottom : 2.5 mm (.100")
Side : 1.8 mm (.072")
GAS TANK
Built-in : ≤ 95 L (25 U.S. gal.)
Look and Configuration
3D Princecraft
®
black chrome logo…UE
Special decal package with 3D Princecraft
®
black chrome logo…UE
Option group
Fishing Package: Tournament Fishing Team graphics, fish ruler, deluxe seat exchange, flat seat base(s) on fishing platform(s), quick rod storage, nets addition under console(s) and on bow platform
Deluxe Package including telescopic stern boarding ladder, 160-watts AM/FM/Bluetooth Jensen
®
radio with 2 speakers and battery switch
Propulsion and autonomy
Tilt steering with slider for captain's chair…UE
SeaStar
®
hydraulic steering system with tilt wheel and slider for captain's chair...UE (included with 150 HP engine and up)
MotorGuide
®
Xi3-70FW wireless trolling motor (24 volts, 60", 70 lb. peak thrust)
MotorGuide
®
Xi5 wireless trolling motor (24 volts, 60", 80 lb. peak thrust)
Minn Kota
®
70 PD V2 trolling motor (24 volts, 60", 70 lb. peak thrust) with bracket
Minn Kota
®
70 Dual spectrum CHIRP trolling motor (24 volts, 60", 70 lb. peak thrust) and bracket
Minn Kota
®
Ulterra 80 trolling motor (24 volts, 60", 80 lb. peak thrust) with iPilot and bracket
Trolling motor onboard charger for 2 - 12V batteries (ProSport 20)
Kicker option with SeaStar
®
hydraulic steering Mercury
®
9.9 PRO-KICKER with remote control and connecting rod
Comfort and entertainment
Bow rider seat cushions
Removable ski pylon
Seat Package: folding seat, post (11") and seat mount with auto-lock handle
Deluxe folding seats…UE (replacing standard seats)
Deluxe Seat Package: folding seat, post (11") and seat mount with auto-lock handle
Bicycle Seat Package: bicycle seat, adjustable post and seat mount with auto-lock handle
RSP Combo: Removable aft flip seats and 2 cup holders
Storage and fishing accessories
Downrigger supports (black)
Downrigger supports (grey)
Downrigger supports (blue)
PrinceTrak storage system
PrinceTrak fish table
PrinceTrak rod holder (installation plate included)
PrinceTrak support
Console and electronic
Sonar Humminbird
®
PiranhaMAX 4
Sonar Humminbird
®
Helix 5 chirp GPS G3 with RAM mount (the bathymetric depth maps are not included)
Sonar/ GPS Humminbird
®
Helix 7 G4 with RAM mount (the bathymetric depth maps are not included)
Sonar/ GPS Humminbird
®
Helix 7 G4 (built-in) (the bathymetric depth maps are not included)
Sonar Lowrance
®
Eagle
®
4X with RAM bracket
Sonar Lowrance
®
Eagle
®
7 Splitshot (the bathymetric depth maps are not included)
Sonar / GPS Lowrance
®
Elite FS 7 (the bathymetric depth maps are not included)
Totalscan sounder for Simrad
®
including down imaging and side imaging
SmartCraft
®
gauges (tachometer, speedometer and trim)…UE
Active trim: automatic trim system
Tops and canvas
Trailer cover (black)
Bimini top on windshield including frame (black)
Converting a bimini top to full top (black)
Miscellaneous
Livewell minnow bucket
Stainless steel propeller model TempestPlus 14 5/8 x 22 for 150 HP PRO-XS…UE
Trailers
Transom tie down straps…/pair
Transom saver motor support bar
ST205/75R14 C galvanized spare wheel with 5 lugs and bracket
14" aluminum mag wheels…UE on galvanized model…(2)
14" aluminum mag spare wheel and bracket (excluding nuts)
